2510 2.54mm Pitch Wire-to-Board Connector

1. 2510 2.54mm Pitch Wire-to-Board Connector&Product Overview

The 2510 Series is a highly versatile,2510 2.54mm Pitch Wire-to-Board Connector system, fully compatible with industry-standard KK 254 types. Known for its robust friction lock design, it ensures a secure connection while remaining easy to assemble, making it the go-to choice for everything from household appliances to industrial control modules.

2. 2510 2.54mm Pitch Wire-to-Board Connector&Technical Specifications

Our 2510 2.54mm Pitch Wire-to-Board Connector series is manufactured using high-grade materials to guarantee long-term electrical stability.

Parameter	Specification
Current Rating	3.0A AC/DC
Voltage Rating	250V AC/DC
Pitch	2.54mm (0.1″)
Contact Resistance	20mΩ Max
Insulation Resistance	1000MΩ Min
Withstanding Voltage	1000V AC/minute
Housing Material	Nylon 66 (UL 94V-0 / V-2 options)
Contact Material	Brass, Tin-plated (Gold-plating available on request)
Applicable Wire	AWG #22 – #28

3. Key Features & Advantages

• Broad Compatibility: Perfectly replaces or mates with standard KK 254 connectors, simplifying your supply chain.

• Secure Friction Lock: The housing features a friction lock mechanism that prevents accidental disconnection due to vibration.

• Flexible Mounting: Available in both Straight (180°) and Right Angle (90°) through-hole versions to fit your PCB layout requirements.

• Multi-Circuit Support: Supports configurations from 2P up to 20P, covering a wide range of signal and power needs.

• High Flame Retardancy: Materials comply with UL 94V-0, ensuring safety in consumer and industrial applications.

4. Typical Applications

Thanks to its 3A current capacity and reliable pitch, the 2510 series is widely used in:

• Home Appliances: Control boards for refrigerators, washing machines, and air conditioners.

• Industrial Automation: PLC modules, sensors, and motor driver interfaces.

• Office Equipment: Internal wiring for printers, 3D printers, and scanners.

• Medical Electronics: Diagnostic equipment and patient monitoring systems.

• Power Modules: Low-power signal distribution and battery management.

5. Why Partner with Shenzhen Longyueda?

As an experienced wire harness factory, we provide more than just components:

• Custom Cable Assemblies: We can provide pre-crimped wires or complete 2510 wire harnesses tailored to your specific lengths and requirements.

• Quality Assurance: Each batch undergoes rigorous testing for insertion force and pull-off strength (following IPC-620 standards).

• Quick Lead Times: Direct factory supply ensures competitive pricing and fast turnaround for small to large scale orders.

5. Why Partner with Shenzhen Longyueda?

As an experienced wire harness factory, we provide more than just components:

• Custom Cable Assemblies: We can provide pre-crimped wires or complete 2510 wire harnesses tailored to your specific lengths and requirements.

• Quality Assurance: Each batch undergoes rigorous testing for insertion force and pull-off strength (following IPC-620 standards).

• Quick Lead Times: Direct factory supply ensures competitive pricing and fast turnaround for small to large scale orders.
