USB-C 24-Pin Side Entry Receptacle: Slim PCB Design for Industrial Applications
In modern PCB design, selecting a reliable USB-C 24-Pin Receptacle is crucial for ensuring high-speed data transfer and durability. In the era of miniaturization, hardware engineers are constantly battling for every millimeter of PCB real estate. As the industry standard shifts entirely toward USB-C, the challenge isn’t just about connectivity—it’s about integration.
The USB-C 24-Pin Side Entry Receptacle (Right Angle) Female Receptacle has emerged as a critical component for designers who need to balance high-speed performance with extreme spatial constraints.
Engineering Precision: Key Features
The 24-pin configuration is the “Gold Standard” for Type-C connectivity, offering full functionality that 6-pin or 16-pin versions cannot match:
- Full Protocol Support: With all 24 pins populated, this connector supports high-speed data transfer (USB 3.1 Gen 2 and beyond), 4K video output (DisplayPort Alt Mode), and high-power delivery (PD) up to 100W.
- Right Angle (Side Entry) Orientation: By mounting parallel to the PCB, this connector reduces the vertical profile to as low as 3.5mm, enabling ultra-slim product architectures for space-constrained designs.
- Enhanced SMT Stability: Designed with robust shielding and reinforced mounting tabs, it provides superior mechanical retention, ensuring the port won’t snap off under the leverage of a heavy cable.
Technical Specifications
| Parameter | Specification |
|---|---|
| Pin Count | 24 pins (Full Type-C) |
| Mounting Type | Right Angle SMT (Side Entry) |
| Data Transfer | USB 3.1 Gen 2 (10 Gbps) / USB4 compatible |
| Power Delivery | Up to 100W (20V/5A, PD 3.0) |
| Video Output | DisplayPort Alt Mode (4K @ 60Hz) |
| Profile Height | 3.5 mm (typical) |
| Operating Temp | -40°C to +85°C |
| Shell Material | Stainless Steel / Hybrid Shield |
| Durability | 10,000+ mating cycles |
Solving Design Challenges with Side Entry USB-C
Why choose a side entry USB-C connector over a standard vertical or mid-mount connector?
- Vertical Height Reduction: Ideal for devices where the casing must be as thin as possible, such as tablets, handheld medical devices, or low-profile IoT sensors.
- Structural Integrity: Side-mount connectors distribute the insertion force horizontally across the PCB surface rather than vertically, which protects the delicate SMT solder joints from fatigue and cracking—critical for industrial USB-C receptacle applications.
- Thermal Management: The low-profile layout (3.5mm) allows for better airflow over the PCB components, preventing heat bottlenecks near the charging port in high-power applications.
Diverse Industry Applications for USB-C 24-Pin Connectors
This connector is not just for consumer gadgets; its durability makes it a staple in professional-grade hardware:
- Industrial Automation: Used in PLC modules and compact controllers where DIN rail space or enclosure depth is limited. The robust SMT design withstands industrial vibration and temperature extremes.
- Drones & Robotics: Provides a lightweight, high-bandwidth interface for data logging and battery management systems where every gram matters.
- Medical Technology: Perfect for portable diagnostic tools that require frequent sterilization and rugged durability. The low profile enables slim medical device enclosures.
- Agricultural Tech: Integrated into ruggedized GPS and monitoring equipment that operates in high-vibration environments. For outdoor applications, consider our USB-C waterproof connector series.
Frequently Asked Questions
What is a USB-C 24-Pin Side Entry Receptacle?
A USB-C 24-Pin Side Entry Receptacle is a right-angle (side entry) female USB Type-C connector with all 24 pins populated. It is designed for space-constrained PCB layouts, offering full USB-C functionality including high-speed data (USB 3.1 Gen 2), video output (DisplayPort Alt Mode), and power delivery up to 100W, all in a low-profile package.
What is the difference between side entry and vertical USB-C connectors?
Side entry (right angle) USB-C connectors mount parallel to the PCB, reducing the vertical profile to approximately 3.5mm. Vertical connectors stand perpendicular to the board, taking up more height. Side entry is preferred for slim devices, while vertical connectors may be used where board space is limited but height is not a constraint.
Can I get free samples of the USB-C 24-Pin Side Entry Connector?
Yes, Longyueda offers engineering samples and bulk pricing for qualified OEM projects. Contact our engineering team with your project requirements and target quantity for a customized quote and datasheet.
What is the operating temperature range for this right-angle USB-C connector?
The USB-C 24-Pin Side Entry Receptacle has an operating temperature range of -40°C to +85°C, making it suitable for industrial, automotive, and outdoor applications that require reliable performance under extreme conditions.
Conclusion
The USB-C 24-Pin Side Entry Receptacle is the ultimate tool for engineers looking to push the boundaries of compact design without sacrificing the high-speed capabilities users demand today. With full 24-pin support, right-angle SMT mounting, and industrial-grade durability, it is the ideal solution for next-generation PCB designs requiring a USB-C industrial connector. For harsh-environment applications, explore our IPX7 waterproof USB-C connector guide for detailed sealing and durability specifications.
📐 Download USB-C 24-Pin Side Entry Datasheet & Request Free Samples →
Contact our Engineering Team Today for technical specifications, 3D models, and bulk pricing.
